CPU | Processor packing | BGA-437 Pin, 22 mm*22 mm |
Support Processor | Mobile Diamondville-SC(Intel Atom N270 ) 1.6GHz |
L2 Cache | 512 KB L2 Cache |
FSB | Up to 533MHz |
Preliminary TDP | 2.5W TDP |
Socket type | SMT on board |
Chipset | Intel 945GSE+82801GBM(ICH7) |
System Memory | DDR2: 400/533 MHz, 1 Channel So-DIMMs, 1G, Max. 2GB |
Display | Panel size | 10.2"TFT LCD panel 1024*600 Backlight unit:LED |
Graphic | Graphic Controller | Integrated Gen3.5 GFX Core, support Linux, XP Home* |
Graphic Memory | Shared system memory |
HDD | 2.5", 9.5mm SATA 5400/7200rpm, 160G |
Move HDD | USB HDD(When shutdown) (Option) |
Audio | Sound Codec chip | ALC269+AT93C46DN(AMP) |
| Internal Speaker | 2.1(BASS)HIGH QUALITY SPEAKERS (1.5W), 3 SPEAKERS |
| Internal Microphone | One |
| Sound Volume | By Function Key |
FM | RDA5802 | Frequency modulation broadcast band 76~108MHz (Option) |
Communications | Wireless LAN | Intel WLAN abg 802.11 b/g |
Modem | Azallia Interface 56K Fax/MODEM (option) |
LAN | 10/100Mbps Etherne 10/100/1000Mbps Ethernett(Option) |
3G | Internal (option) |
CDMA card | Internal (option) |
Bluetooth | Internal (option) |
Input Device | Keyboard | 254.75mm×96.4mm |
UK/EU/JP/BZ Standard Supported (82 key) |
Hot Keys | 2 Multifunctional key |
TouchPad | Glide, with 2 buttons |
I/O Ports | 1 x Mic in |
1 x Headphone out |
1 x RJ-45 |
3 x USB 2.0 Ports |
1 x DC-in |
1 x VGA (15Pin) |
Expansion Slots | Card Reader | 3 in 1 (/SD/MS/MMC) |
Build-in Web Camera | 1.3M Pixels |
Function Keys | Fn+F1 | Sleep |
| Fn+F2 | Camera ON/OFF |
Fn+F3 | Dual Display |
Fn+F4 | TouchPAD ON/OF |
Fn+F5 | Speaker ON/OFF |
Fn+F6 | Speaker Volume/ Down |
Fn+F7 | Speaker Volume/ up |
Fn+F8 | LCD brightness/ Down |
Fn+F9 | LCD brightness/ UP |
Fn+F10 | LCD ON/OFF |
Security Features | Kensington Lock(Option) |
Head portrait identify(Option) |
TCM(Option) |
Status Indicator | On/Off/Suspend | Blue LED On/Off/Flash |
Battery Charging | Charging On:Blue LED on, Fully Charged: LED Off |
Low Battery (No AC) : 3%-6% : battery led off, power led flash, power blue led flash <3%: battery led off, power led flash, power blue led off
|
Keyboard | Capital, Number : Green LED On When |
HDD Read/Write | Blue LED On |
Hot Keys | 1 Status key;After press display all status info on screen. |
Power | AC Adapter | Input: 100~ 240V AC, 50/60Hz |
3A 15Volt (TBD) |
3.42A 19 Volt 3.5A 18.5Volt |
Battery Pack | 3 cells(Li-ion), 2200mAh |
Coulomb Display | Battery (NO AC) when Shut down 1%~10% Power LED RED on 10%-20% PowerLED RED on 20%~40% NumberLock, CapLock LED Blue on 40%~60% NumberLock, CapLock, Bettery LED Blue on 60%~80% NumberLock, CapLock, Bettery, Power LED Blue on 80%~100% NumberLocK, CapLock, Bettery, Power, WLAN LED Blue on |
Physical Characteristics | Dimension | 265mm×185mm |
| Thickness | 28.8mm |
| Weight | 1.2KG |
OS | Win XP |
Linux |
