Dry Transformer - H-class

Dry Transformer

Item No.: H-class
Supplier Details
Country: China
City:
Address:
TEL: +--
Fax: +--
Online Showroom: 33 Products

Product standard:GB1094.11-2007  GB/T10228-2008 IEC60726

Rated high voltage available:6,6,310,10.5,11kV,rated low voltage:0.4kV

HV tapping rage:+2×2.5% or +5% Symbol of vector group:Dyn11 or Yyn0

Insulation level:L175AC35/AC5

Technical Parameters:

ModelOpen circuit losses120oC Load losses at 120oCOpen circuit currentShort-circuit impedanceGross weightGauge and instllation sizeDimension(mm)
C
 (W)(W)%%(kg)(mm)A×B×C
SG11-200/1052028801.441170660×6601270×710×1218
SG11-250/1059033001.41340820×8201300×870×1310
SG11-315/1070039701.41630820×8201340×870×1390
SG11-400/1080046401.31940820×8201360×870×1540
SGB11-500/1094055301.32190820×8201430×870×1680
SGB11-630/10104068001.262340820×8201610×870×1500
SGB11-800/10123079001.22490820×8201670×870×1600
SGB11-1000/10140094200.93000820×8201720×870×1640
SGB11-1250/101620111400.93430820×8201770×870×1820
SGB11-1600/102160136500.94140820×10701780×1120×1990
SGB11-2000/102400165400.847801070×10701920×1120×2030
SGB11-2500/102800197200.856101070×10702070×1120×2110
We have been successful in establishing our brand and sale to the international market due to our excellent quality and service of

Dry Transformer

. Delivering the best quality products conforming to the cultural needs of the client is the ultimate goal of us.
