Solder Machine
| Item No.: | ETS-2E |
Supplier Details
Country: Taiwan
City: NEW TAIPEI
Address: NO.8,LN.302,XINSHU RD.,XINZHUANG DIST.,NEW TAIPEI CITY 242,TAIWAN(R.O.C.)
TEL: +886-2-22060881
Fax: +886-2-22060800
Online Showroom:
33 Products
Technical Specifications:
Item NO.ETS-2E
Soldering way: Jig up/down
Power source: AC220V 2000W
Machine dimension: 500(L) x 850 (W) x 660(H)mm
Weight / Air pressure: 75KGS/5kgs/cm2
Inner pot size: 295(L) x 105 (W) x 65(H)mm
Cycle time :10-20 pcs / 8-10sec
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: any coil
Dip cup up/down distance: 76mm (Controlled by Cylinder)
OPTIONS:
Suit Coil: Transformer, Relay, Fans Motor, Inductance… any coil
Features:
Item NO.ETS-2E
Soldering way: Jig up/down
Power source: AC220V 2000W
Machine dimension: 500(L) x 850 (W) x 660(H)mm
Weight / Air pressure: 75KGS/5kgs/cm2
Inner pot size: 295(L) x 105 (W) x 65(H)mm
Cycle time :10-20 pcs / 8-10sec
Pot Material: Titanium
Temperature: 600℃ Max.
Suitable coil: any coil
Dip cup up/down distance: 76mm (Controlled by Cylinder)
OPTIONS:
- Dip flux automatically
- Feed solder automatically
- Leave solder dross after dip solder
- Servo motor control, Dip cup up down
Suit Coil: Transformer, Relay, Fans Motor, Inductance… any coil
Features:
- Soldering pot made by Titanium, meet lead-free
- Soldering Time Control.
- Digital Temperature Control.
