DKM 2U
| Item No.: | DKM 2U |
Supplier Details
Country: Taiwan
City: NEW TAIPEI CITY
Address: NO.245, JHONGJHENG RD., SHULIN DIST., NEW TAIPEI CITY 238, TAIWAN (R.O.C.)
TEL: +886-2-26825650
Fax: +886-2-26825649
Online Showroom:
17 Products
Industrial Rackmount Keyboard Drawer with LCD Monitor
Utilizing only 1U or 2U of rack space, the DKM series combined a keyboard with glide point touch-pad, Active Matrix LCD monitor and a pair of amplified stereo speakers in a rugged rackmount drawer. With the slide rails included, the unit can be fit to any standard rack chassis ranging from 16.25″ to 36″ deep. These simply save you valuable rack space to optimize and maximize the use of the rack. A short travel of 13″ pull is sufficient to clear the rack and raise the LCD monitor to a comfortable viewing position. The drawer conveniently slides smoothly away when not in use.
Analog-to-Digital Conversion Board
A built-in smart Analog-Digital conversion board is behind the technology in interfacing the digital LCD monitor with standard analog VGA output, allowing compatibility with almost all VGA controllers. The conversion board also features an On Screen Display (OSD) for fine-tuning the display in Linux/Unix text and graphical interface.
LCD Flat Panel Monitor
The LCD monitor is built inside a slim and rugged aluminum housing for durability. The display mechanism is hinged so that it can be tilted to the most comfortable viewing position. LCD lay flat on top of keyboard when recessed into the drawer. An auto shut-off switch will turn-off the power to the LCD monitor when the LCD is in recess position.
Keyboard and Pointing Device
The DKM comes standard with a 105 keys membrane keyboard. The keyboard is secured to the drawer and flushed in an aluminum housing. You have selcetion of touch-pad with two buttons or a standard PS/2 mouse.
Optional TV Tuner
A special model with TV Tuner built-in and remote. 17″ LCD with VGA, RCA, BNC and S-Video inputs.
Power Supply and Ports
The LCD flat panel monitor is powered by a 60W 100-240V full-range power supply positioned at the back of the drawer with a rocker on-off switch. The keyboard, pointing device and VGA connectors are also positioned at the back of the drawer for easy access.
Finish and Security
The DKM is available in color black with power coated finish. A key locking mechanism locks the drawer when in the full recess position, to prevent unauthorized access.
1. 1U design with 15″ and 17″ TFT LCD
2. 2U design with 17.3″ and 20″ TFT LCD
3. 16:9 wide screen LCD on certain models
4. Built-in amplified speakers
5. USB with HUB on certain models
6. Built-in touch pad pointing device or standard PS/2 mouse
7. Work with standard AGP video
8. DVI inputs on certain models
Utilizing only 1U or 2U of rack space, the DKM series combined a keyboard with glide point touch-pad, Active Matrix LCD monitor and a pair of amplified stereo speakers in a rugged rackmount drawer. With the slide rails included, the unit can be fit to any standard rack chassis ranging from 16.25″ to 36″ deep. These simply save you valuable rack space to optimize and maximize the use of the rack. A short travel of 13″ pull is sufficient to clear the rack and raise the LCD monitor to a comfortable viewing position. The drawer conveniently slides smoothly away when not in use.
Analog-to-Digital Conversion Board
A built-in smart Analog-Digital conversion board is behind the technology in interfacing the digital LCD monitor with standard analog VGA output, allowing compatibility with almost all VGA controllers. The conversion board also features an On Screen Display (OSD) for fine-tuning the display in Linux/Unix text and graphical interface.
LCD Flat Panel Monitor
The LCD monitor is built inside a slim and rugged aluminum housing for durability. The display mechanism is hinged so that it can be tilted to the most comfortable viewing position. LCD lay flat on top of keyboard when recessed into the drawer. An auto shut-off switch will turn-off the power to the LCD monitor when the LCD is in recess position.
Keyboard and Pointing Device
The DKM comes standard with a 105 keys membrane keyboard. The keyboard is secured to the drawer and flushed in an aluminum housing. You have selcetion of touch-pad with two buttons or a standard PS/2 mouse.
Optional TV Tuner
A special model with TV Tuner built-in and remote. 17″ LCD with VGA, RCA, BNC and S-Video inputs.
Power Supply and Ports
The LCD flat panel monitor is powered by a 60W 100-240V full-range power supply positioned at the back of the drawer with a rocker on-off switch. The keyboard, pointing device and VGA connectors are also positioned at the back of the drawer for easy access.
Finish and Security
The DKM is available in color black with power coated finish. A key locking mechanism locks the drawer when in the full recess position, to prevent unauthorized access.
1. 1U design with 15″ and 17″ TFT LCD
2. 2U design with 17.3″ and 20″ TFT LCD
3. 16:9 wide screen LCD on certain models
4. Built-in amplified speakers
5. USB with HUB on certain models
6. Built-in touch pad pointing device or standard PS/2 mouse
7. Work with standard AGP video
8. DVI inputs on certain models
