Ideal for materials with poor flow characteristics

Equipped with 4 inches ECON transfer pumps that generate up to 5:1 output pressure ratio, COSMOSTAR CY-1302 transfer pumps are specialized to handle semi-viscous materials with flow-rate up to 9.5 liters/minute. COSMOSTAR CY-1302 transfer pumps are the most affordable series of COSMOSTAR transfer pumps and designed for low cost applications.

Features and Benefits
Air-operated for high reliability and low cost
Delivery up to 9.5 liters per minute and operating pressure up to 40 bars
Available in stainless steel or carbon steel

Typical Application
Fluid transfer and supply
Paint circulating
Cleaning and chemical supply

Typical Fluids Handled
Solvent borne paints
Waterborne paints
Texture coatings
Cleaning fluids

Technical Data
Air motor diameter     4 in (ECON)
Pressure ratio     5:1
Maximum Fluid Working Pressure    600 PSI (40 Bar)
Maximum Air Input Pressure    120 PSI ( 8 Bars)
Maximum volume flow rates     9.5 LPM
Maximum Recommended Pump Speed    60 cycles per min
Air inlet size      3/8 and 1/2 npt(f)
Fluid inlet size     1-1/2 npt(f)
Fluid outlet size      3/4 npt(f)
Dimension      1.48 m (length)
